VIEW Design & Build Plans

1 BED | 1 KIT | 1 BATH - Dimensions W x D x H

View. Designed for sites with decent gradients but equally at home on level land, 1 x 40ft (12) and 2 × 20ft (6m) shipping containers are combined in a perfect union to create the feel of an amply proportioned 1 Bedroom home or holiday getaway.

Download detailed plans for VIEW which include the following drawings in A3:

DRAWINGS SCHEDULES

PROJECT NOTES

FLOOR PLAN

REFLECTED CEILING

ROOF PLAN

ELEVATIONS

SECTIONS

INTERNAL ELEVATIONS

TYPICAL DETAILS

KITCHEN DRAWINGS

JOINERY DRAWINGS

BATHROOM DRAWINGS

ASSEMBLY DRAWINGS

WINDOW SCHEDULES

LIGHTING PLAN

POWER & SWITCHES PLAN

ELECTRICAL SCHEMATICS

FIXTURES & FINISHES SCHEDULE

Bespoke plans or amendments are also available from Interbode’s Design Studio. Contact Us: https://www.interbode.com

Notes:

1. Whilst detailed, this document is not for construction and is not intended to be compliant with all council or building regulations in your country or state. Prior to commencing build you should engage a suitable architect/drafts person and a qualified engineer.

2. All plans are copyright of Interbode Pty Ltd and Boxwood Construction Pty Ltd.
