HELI Design & Build Plans

1 BED | 1 KIT | 1 BATH - Dimensions W x D x H

Heli is a double unit 2X 12M (20ft) High Cube Shipping containers design suitable for flat sites/site needing to elevate in order to obtain views.

Download detailed plans for HELI which include the following drawings in A3:

DRAWINGS SCHEDULES

PROJECT NOTES

FLOOR PLAN

REFLECTED CEILING

ROOF PLAN

ELEVATIONS

SECTIONS

INTERNAL ELEVATIONS

TYPICAL DETAILS

KITCHEN DRAWINGS

JOINERY DRAWINGS

BATHROOM DRAWINGS

ASSEMBLY DRAWINGS

WINDOW SCHEDULES

LIGHTING PLAN

POWER & SWITCHES PLAN

ELECTRICAL SCHEMATICS

FIXTURES & FINISHES SCHEDULE

Bespoke plans or amendments are also available from Interbode’s Design Studio. Contact Us: https://www.interbode.com

Notes:

1. Whilst detailed, this document is not for construction and is not intended to be compliant with all council or building regulations in your country or state. Prior to commencing build you should engage a suitable architect/drafts person and a qualified engineer.

2. All plans are copyright of Interbode Pty Ltd and Boxwood Construction Pty Ltd.
